TrueX Soil Heavy Metal Analyzer
The TrueX handheld soil heavy metal analyzer is a portable and lightweight device that operates with just one button. It can perform multi-element analysis and detection for various soil and sediment samples (tested solids, powders, powders, solids, debris, mud filter materials, thin film layers, and other tangible objects) and quickly obtain reliable analytical data. It helps develop real-time strategies, and the testing costs are much lower compared to laboratory analyses.
Gallery
Features
Remediation methods to provide a theoretical basis for in-depth analysis of original land, on-site disposal of polluted water, wastewater, and other harmful substances, and pollution control.
Analysis of sand, mud, solid waste, soil, sludge; Dust, powder, filter, film layer, etc.
Technical Parameters
| Weight | 1.5kg |
| Size | 254mm×79mm×280mm（L×W×H） |
| Excitation source | 50kV/200μA upper limit, tube pressure tube flow can be adjusted freely, W/Ag/Rh target (optional) |
| Detector | Si-PIN detector/SDD detector |
| Detection range | Mg—U |
| Display system |
4.3 "industrial grade resistance touch screen Automatically adjust display brightness according to external environment brightness |
| Data processing |
Built-in 32GB storage USB,can connect the device to the Internet, remote setting and maintenance of the instrument |
| Security |
Built-in DoubleBeam™ technology automatically senses samples ahead for enhanced radiation safety and protection Waterproof, dustproof and shockproof carrying case LANScientific special safety rope |
| Power system |
Intelligent battery with MSBUS, real-time monitoring battery, spare battery can directly check the remaining capacity of the battery, the battery complies with the air dangerous goods transport regulations A single battery can work for about 8 hours |
| Language | Chinese, English, etc |
Advantages
Excellent performance
Element symbols are displayed in both Turkish and English, offering high sensitivity and fast speed, close to laboratory-level analysis. It intuitively shows the element percentage content (elements can be displayed up to three decimal places) and PPM content.
One click transaction
The entire analysis process takes only a few seconds. Soil can be analyzed directly in the field without the need for sample preparation.
Even individuals without technical knowledge can easily learn to use it.
Non-Destructive Testing (NDT)
No damage occurs, it does not affect the performance of the tested sample, and the entire testing process is carried out without any harm.
Easy customization
It offers various customizable settings based on the test. You can modify test conditions according to detection needs or adjust thresholds based on scanning requirements, enabling personalized scanning of different materials and elements.
Performing wave analysis
Professional management and analysis software allows you to easily set security user passwords, perform remote control of the device with customized, personalized analysis reports featuring the company logo; enables users to access the device calibration method so they can calibrate the device and perform energy calibration; supports automatic calibration and device fault diagnosis; software can be upgraded via the Internet.
Data processing
USB, WIFI, wireless Bluetooth, and other data transmission methods are supported. Files can be in EXCEL, PDF, and other formats. Users can customize test reports to include company logo, company address, test results, spectral spectrum, and other sample information (such as product description, origin, batch number, etc.). Cloud data services can be provided. Supports organization and enterprise resource planning (ERP) production resource planning management.
