TrueX 980 Portable XRF Analyzer – Metal Analysis Device

The TrueX handheld XRF metal analyzer is developed with advanced XRF technology that takes metal analysis and material identification in production processes to the next level. Its lightweight and portable design, high-precision XRF measurement capability, and fast analysis time ensure maximum efficiency both in the field and on production lines.

The TrueX handheld XRF device enables on-site analysis and instant sorting, delivering reliable and repeatable results in applications such as alloy analysis, quality control, and recycling. It is widely used across various industries, including steel and non-ferrous metals, as well as petrochemical, energy, and pharmaceutical sectors.

The TrueX handheld XRF metal analyzer allows businesses to make data-driven decisions, improve production efficiency, and sustainably maintain international quality standards.

Gallery

Features

Quality Control and QA (QC/QA) and Effective Error Prevention (PKKA-YOKE)

Alloy material identification (PMI) inlet inspection

Waste recycling and separation

Technical Parameters

Weight	1.5kg
Size	254mm×79mm×280mm（L×W×H）
Detection range	Mg—U
Excitation source	50kV/200μA upper limit, tube pressure tube flow can be adjusted freely, W/Ag/Rh target (optional)
Detector	Si-PIN detector/SDD detector
Display system	4.3 "industrial grade resistance touch screen Automatically adjust display brightness according to external environment brightness
Data processing	Built-in 32GB storage USB, can connect the device to the Internet, remote setting and maintenance of the instrument
Heat dissipation	The instrument is equipped with a special T-slot heat sink to improve the heat dissipation performance of the instrument, eliminating the need to frequently wait for the detector to cool down.
Security	Built-in DoubleBeam™ technology automatically senses samples ahead for enhanced radiation safety and protection Waterproof, dustproof and shockproof carrying case LANScientific special safety rope
Power system	Intelligent battery with MSBUS, real-time monitoring battery, spare battery can directly check the remaining capacity of the battery, the battery complies with the air dangerous goods transport regulations A single battery can work for about 8 hours

Advantages

Personalized

 Professional management and analysis software allows you to set security passwords and generate customized, personalized analysis reports featuring your company logo.

Extremely low detection limit

 The new super-FP algorithm, a precise strength adaptation method, enables users to accurately analyze metal materials and elemental content without switching modes.

Professional brand database

 The product's built-in brand database contains 380 alloy brands, solving the conversion issues of different country brands in specialized industry applications. At the same time, users can customize and expand the alloy brand library, enabling simultaneous analysis of over 600 alloy types and more than 10,000 alloy materials.

Non-destructive testing (NDT)

 The entire testing process does not cause any damage to the product, and measurements can be performed under various extreme environmental conditions such as high and low temperatures, dust, darkness, and humidity.

More portable

 One-touch operation for greater convenience; the instrument is smaller and lighter, making it easy for users to carry, and remote control of the instrument can be easily performed.
